5050-RGB-60LED-12MM-24V-14W-UCS1903-10Pixels-Long Run 15M
Addressable RGB UCS1903 IC Digital 60LED DC 24V 14W IP20 3OZ 12mm Led Strip
This RGB digital strip uses an external UCS1903 IC and features a 3Oz, 12mm PCB for high stability. It supports up to 15 meters without voltage drop, making it much easier to install compared to standard strips that require frequent feed power . Compatible with most pixel controllers like K1000, SP108E, and comes with 3M double-sided tape for quick mounting.
- DC24V Input Voltage
- UCS1903, individually pixels controlled
- 5050 60LED per meter, 10pixels/m
- Work with SPI Pixel lighting controller
- 12mm 3Oz PCB with good heat dissipation
- Work on 15M in series without voltage dropping
- Easy Installation featuring 3M 300LSE Adhesive Layer
- Cut unit 100mm
- 50,000hours rated life / 3 years warranty
Order Information
| Model | Voltage | Power/M | Pixels/M | LED Type | Qty | Angle | CRI | Color | Cut Unit | Brightness | Effiacy | Max Run |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S12W20-5050TC-024AD-060S-NY3-UCS1903 | 24V | 14W | 10 | 5050 | 60 | 120 | N / A | RGB | 100mm | N / A | N / A | 15M |
Download
