1515 Side Bend Neon flex DC 14W 24V IP67 outdoor waterproof 2835 Led Neon flex
- Made of high quality silicone
- Integrated extrusion molding process
- Available in multiple color options: White, CCT, RGB, RGBW, with SPI and DMX support
- Flexible ‘side bend’ design for creative LED strip installation
- IP67 protection level, salt solution resistance, acids and alkalis and UV resistance
- High efficacy up to 450 lm per meter
- width 16mm, height 16mm
- 80+ color rendering index, Ra90 is available
- Cut unit 50mm, Easy installation
- 50,000 hours rated life / 3 year warranty
This 1515 Side Bend Neon Flex features 140 LEDs per meter and is encapsulated in high-quality silicone, making it suitable for both indoor and outdoor applications. Its side-bend design (W15mm × H15mm) allows creative installations, while the high-CRI light source (80+, optional Ra90) ensures accurate color rendering and bright, uniform illumination. The flex is UV- and saltwater-resistant, providing durability against environmental factors.
Built with an integrated extrusion molding process, the strip delivers up to 450 lm per meter and is available in multiple color options, including White, CCT, RGB, and RGBW, with SPI and DMX support. It is cuttable every 50mm and includes easy installation features. With a 50,000-hour rated life and 3-year warranty, it offers a reliable, high-performance lighting solution for decorative and functional applications.
Order Information
Single Color Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-283527-024CV-140S-WYX-S1515 | 24V | 2700K | 14W | 2835 | 140 | 60 | IP67 | 90 | 50mm/7LEDs |
| N10W67-283530-024CV-140S-WYX-S1515 | 24V | 3000K | 14W | 2835 | 140 | 65 | IP67 | 90 | 50mm/7LEDs |
| N10W67-283540-024CV-140S-WYX-S1515 | 24V | 4000K | 14W | 2835 | 140 | 70 | IP67 | 90 | 50mm/7LEDs |
| N10W67-283560-024CV-140S-WYX-S1515 | 24V | 6000K | 14W | 2835 | 140 | 65 | IP67 | 90 | 50mm/7LEDs |
Mini Cut Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-283527-024CV-168S-WYX-S1515 | 24V | 2700K | 14W | 2835 | 168 | 60 | IP67 | 90 | 11.9mm/2LEDs |
| N10W67-283530-024CV-168S-WYX-S1515 | 24V | 3000K | 14W | 2835 | 168 | 65 | IP67 | 90 | 11.9mm/2LEDs |
| N10W67-283540-024CV-168S-WYX-S1515 | 24V | 4000K | 14W | 2835 | 168 | 70 | IP67 | 90 | 11.9mm/2LEDs |
| N10W67-283560-024CV-168S-WYX-S1515 | 24V | 6000K | 14W | 2835 | 168 | 65 | IP67 | 90 | 11.9mm/2LEDs |
CCT Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-2216TW-024CV-240S-WYX-S1616 | 24V | 2700-6000K | 16W | 2216 | 240 | 41 | IP67 | 90 | 50mm/2LEDs |
RGB Options
| Model | Voltage | Color | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-3838TC-024CV-120S-NYX-S1515 | 24V | RGB | 15W | 3838 | 120 | N / A | IP67 | N / A | 50mm/6LEDs |
RGBW Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N12W67-5050MC-024CV-096S-MYX-S1515 | 24V | RGBW | 20W | 5050 | 84 | N / A | IP67 | N / A | 62.5mm / 6LEDs |
SPI Options
| Model | Voltage | Color | Power | LED Type | LED Qty | Pixels (Pixels/M) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-2835XX-024AD-120S-WYX-S1515 | 24V | White SPI | 10W | 2835 | 120 | 20 | IP67 | 90 | 50mm/6LEDs |
| N10W67-2835TC-024AD-120S-WYX-S1515 | 24V | RGB SPI | 11W | 2835 | 120 | 20 | IP67 | N / A | 50mm/6LEDs |
| N12W67-5050MC-024AD-084S-WY3-S1515 | 24V | RGBW SPI | 15W | 5050 | 84 | 14 | IP67 | N / A | 71.42mm/6LEDs |
DMX Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Pixels (Pixels/M) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| N10W67-2835XX-024DMX-120S-WY3-S1515 | 24V | White DMX | 18W | 2835 | 120 | 10 | IP67 | 90 | 100mm / 6LEDs |
| N12W67-5050TC-024DMX-084S-WY3-S1515 | 24V | RGB DMX | 18W | 5050 | 84 | 12 | IP67 | N / A | 71.42mm / 6LEDs |
| N12W67-5050MC-024DMX-084S-WY3-S1515 | 24V | RGBW DMX | 20W | 5050 | 84 | 14 | IP67 | N / A | 71.42mm / 6LEDs |
Download
Accessories
2CL-1515-002
Aluminun Clip for 16*16 neon flex, 20mm length, with Hole
2AP-1515-100
Aluminun Channel for 16*16 neon flex, 1000mm length, with 2pcs Holes
2FC-1515-XXX
Flexible neon channel, for 16*16 neon flex, customized length
2EN-1515-SOH
End cap (without hole), silicone material, for 16*16 neon flex
2EN-1515-SSH
End cap (with hole at side face) silicone material, for 16*16 neon flex
2EN-1515-STH
End cap (with hole at top face) silicone material, for 16*16 neon flex.
