2835 White 120LED DC 12V 12W IP67 outdoor waterproof 2835 Led Strip Light
- DC12V Input Voltage
- 3Oz 10mm PCB
- 2835 LED, 120 LEDs, 3 leds per set
- Reaching 1150lm/m
- White is available at 2700K, 3000K, 4000K, 6000K
- IP20, IP65, IP66, IP67 is available
- Cuttable every 25mm
- 50,000 hours rated life
Decriptions
The 2835 LED Strip features 120 LEDs per meter, arranged in sets of 3 LEDs, delivering a luminous output of 1150lm/m. Operating on DC 12V with a power consumption of 12W per meter, it provides efficient and stable illumination. Available in color temperatures from 2700K to 6000K, it covers all intermediate tones to create elegant lighting for a variety of applications.
Designed for easy installation, the strip includes double-sided 3M adhesive backing and is cuttable every 25mm, making it suitable for LED channels or custom layouts. With IP20, IP65, IP66, and IP67 protection options, an 80+ CRI (Ra90 is optional), and a rated life of 50,000 hours with a 3-year warranty, this strip ensures long-lasting, high-quality performance.
Order Information
Single Color Options
| Model | Voltage | Color (K) | Power | LED Type | LED Qty | Efficacy (lm/W) | IP Rating | CRI | Cuttable Length |
|---|---|---|---|---|---|---|---|---|---|
| S08WXX-283527-012CV-120S-WY3 | 12V | 2700K | 12W | 2835 | 120 | 85 | IP67 | 90 | 25mm/3LEDs |
| S08WXX-283530-012CV-120S-WY3 | 12V | 3000K | 12W | 2835 | 120 | 90 | IP67 | 90 | 25mm/3LEDs |
| S08WXX-283540-012CV-120S-WY3 | 12V | 4000K | 12W | 2835 | 120 | 95 | IP67 | 90 | 25mm/3LEDs |
| S08WXX-283560-012CV-120S-WY3 | 12V | 6000K | 12W | 2835 | 120 | 90 | IP67 | 90 | 25mm/3LEDs |
Download
Accessories
Strip to strip connector
Transparent Acrylic,10mm PCB with 2pins, non waterproof, strip to strip
Strip to Wire
Transparent Acrylic, 10mm PCB with 4pins, 150mm lenght wire, non waterproof strip to Power
Strip to strip with wire
Transparent Acrylic, 10mm PCB with 2pins, 150mm wire, both ends with connector.non waterproof, strip to strip
